PTK 200W Portable Solar Panel Kit Briefcase


PTK 200W Portable Solar Panel Kit Briefcase from ACOPOWER for retail price $485.99. Get more discount today in our store. Don’t Miss it!

Check Availability



PTK 200W Portable Solar Panel – ACOPOWER All Black 200W Mono Foldable Solar Panel Kit with Charge Controller is the key component to a system when going solar Off-Grid system. The 200w solar panels are relatively compact and are a breeze to set up. Whether you are going camping in the mountains or taking a trip to the beach, this solar suitcase can be a great start to your off-grid system! This solar kit has several uses including marine, dry camp, RVS, and other off-grid applications.

PTK 200W Portable Solar Panel Kit Briefcase

PTK 200W Portable Solar Panel
BrandACOPOWERTypeSolar Panel
Open Full Specifications

Key Features

  • Negative Ground Controller Featuring Advanced MPPT Technology with High Tracking Efficiency up to 99.5% and Peak Conversion Efficiency of 98%. Maximizing the Energy From Solar Panels to Charge your System. With Temperature Sensor, Automatic Temperature Compensation The Solar Panel’s Power Generation 10~20% Higher than the PWM Solar Charge Controller
  • Four 50W solar panels attached in pairs for portability. Case design facilitates transportation and helps keep solar panel safe when storing
  • Grade A monocrystalline solar panels with 20A waterproof charge controller, MC-4 connector, and alligator clips makes this product an ideal option for 12V battery charging
  • The pre-installed stand allows for easy and quick set-up. MC-4 connectors or Anderson plug allow easy installation to RV or battery unit
  • Aluminum frame, corner protectors, lock-latches, and carrying handle make this a lightweight and portable product

Package List

  • 2 x 100W Portable Solar Panel
  • 1 x 20A charge controller
  • 3 x User Manual


Module Type: 2×50WMaximum Power: 2x100W
Open-Circuit Voltage (Voc): 22.3VMaximum Operating Voltage (Vmp): 17.8V
Short-Circuit Current (Isc): 2 x 1.3.03AMaximum Operating Current (Imp): 2 x 1.81A
Folded size: 25.6×19.9×1.2 in / 650x505x30mmUnfolded size:
Weight: 66.2 lbs / 30kg


Nominal Voltage: 12V/24V DCRated Charge Current: 20A
Max. PV Input Voltage: 50VGrounding: Common Negative
Battery Start Charging Voltage: 3VTemperature Compensation Coefficient: -24mV/°C
Operating Temperature: -40°F to 140°FStorage Temperature: -40°F to 185°F
Terminals: Up to 10 AWGEnclosure: IP65
Dimensions: 5.59x 3.7x 1.06 inchesWeight: 1.1 lbs
